Fine stone concrete pump
  • Name：

    Fine stone concrete pump

  • Description：
    Brief introduction of Xbs series fine aggregate concrete pump of Jeddah heavy industry: Xbs series fine aggregate concret..

Product Details




Brief introduction of Xbs series fine aggregate concrete pump of Jeddah heavy industry: Xbs series fine aggregate concrete pump products are applicable to the transportation of fine aggregate concrete, refractory and thermal insulation materials, green soil in ecological environment construction and pressure grouting of various foundation piles.

Characteristics of fine aggregate concrete pump:

Fine aggregate concrete pump adopts s-pipe valve reversing, which can meet the transportation of fine aggregate concrete;

The spectacle plate and cutting ring of fine aggregate concrete pump are made of high hard alloy material with long service life;

The outlet pressure of fine aggregate concrete pump is high, which can meet the transportation requirements of high-rise buildings and long-distance construction;

The hydraulic oil cooling of fine aggregate concrete pump adopts water cooling system, which has good cooling effect and easy to use;

Fine aggregate concrete pump has the function of reverse pump to reduce pipe blockage;

Equipped with manual centralized lubrication system, the service life of rotating parts;

The electrical box is equipped with wired remote control handle for easy operation.

细石混凝土泵技术参数（parameter）：
项目 单位XBS20-08-33XBS25-10-37XBS30-10-45XBS40-12-55
理论输送量  Theoretical conveying capacitym3/h20253040
出口压力  Outlet pressure Mpa8101012
骨料粒径  Aggregate sizemm≤20≤20≤20≤20
缸径×行程  Cylinder bore × tripmmø120×800ø120×1000ø140×1000ø160×1000
主电机   Main motorkw33374555
输送管内径 Inner diameter of conveying pipemmø80ø80ø100（ø80）ø100（ø80）
外形尺寸 Overall dimensionmm4000×1400×15004000×1500×15504500×1500×16004600×1550×1800
重量 weight㎏2000210022002400
理论输送距离 Theoretical conveying distancem水平Horizontal350水平Horizontal350水平Horizontal400水平Horizontal500
垂直Vertical110垂直Vertical120垂直Vertical150垂直Vertical150
